Bowers & Wilkins CCM382
The CCM382 shallow-form in-ceiling speaker features a 25mm soft-dome tweeter and 200mm mid/bass driver for impressive sound. Engineered to deliver precision sound in any environment, CCM382 will bring your music and movies to life.
Bowers & Wilkins CCM382
Sale price
Regular price (/)
Bowers & Wilkins CCM382 In-Ceiling Speakers
- Shallow form factor suits any potential installation space.
- Flexible 2-way in-ceiling system with 8 inch form.
- Baffle, frame, bezel, grille.
- Cut-out template, paint mask.
Design
2-way in-ceiling system
Drive Units
1x 25mm (1in) soft dome tweeter
1x 200mm (8in) Polypropylene cone bass/midrange
Frequency Range (-6dB)
45Hz - 30kHz
Recommended Amp Power
25 – 130w
Sensitivity SPL (2.83V, 1m)
90 dB
Impedance Nominal (min)
8 ohms (5.0 ohms)
Frame Dimensions
Frame Diameter: 11.4 Depth Behind Surface: 3.4 "
Cut-out Dimensions
Cut-out diameter: 9.9 " Protrusion: 0.2 "
Power Handling
80W
Pre-mount Kit
PMK C8
Recommended Back Box
BB 6C
Approximate Weight
Shipping: 10 lbs
UPC
714346313617
Series
CI 300 Series
Frequency Response
45-30kHz
Impedance
8 Ohms
power_range
10-80 watts
Sensitivity
90 dB
Tweeter
Soft-dome
