Bowers & Wilkins CCM683
The CCM683 is a true high-performance ceiling-mount speaker. The speaker features a 200mm (8in) woven blue Aramid Fibre cone bass/midrange driver and an aluminium tweeter in a neat circular die-cast chassis. The tweeter’s housing pivots for adjustable off-axis treble response and the die-cast chassis provides extra rigidity that results in a cleaner, faster bass.
Bowers & Wilkins CCM683 In Ceiling Speakers
The CCM683 has a rotating tweeter with the same type of EQ controls as the CCM664; however, the speaker components are all upgraded. These use a 1” Nautilus™ swirl-loaded aluminum dome tweeter coupled with a larger 8” midrange/woofer. The cone material used for this driver steps up to their blue Aramid Fibre. The CCM683 is the least expensive model where you get the larger 8” woofer and these better drivers which is one reason it's on our shortlist of the best Bowers & Wilkins in-ceiling speakers.
2-way in-ceiling system
1x ø25mm (1 in) Nautilus™ swirl loaded aluminum dome tweeter
1x ø200mm (8in) blue aramid fiber cone bass/midrange
35Hz – 50kHz
25 – 130w
88 dB
8 ohms (4.5 ohms)
Frame Dimensions
Frame Diameter: 11.4"
Depth Behind Surface: 5.2 "
Cut-out diameter: 9.8 "Protrusion: 0.2"
C8
C6
Shipping: 10 lbs
714346310395
CI 600 Series
1x ø25mm (1 in) Nautilus swirl loaded aluminum dome tweeter
1x ø200mm (8in) blue Aramid Fibre cone bass/midrange
8Ohms (minimum 4.5Ohms)
88 dB
Recommended 25 – 130w
