Cambridge Audio Edge W
The Cambridge Audio Edge W is a high-fidelity stereo power amplifier designed to deliver dynamic and punchy sound with exceptional musicality. It features a minimalist design with only 14 carefully selected components in the signal path, ensuring a clean and unadulterated audio experience.
Cambridge Audio Edge W Power Amplifier
- Hand-picked components – hours of listening to select only those that sound the best.
- Twin Toroidal Transformers – huge reserves of power for consistent tonality.
- Cambridge Audio proprietary Class XA Amplification - no audible crossover distortion.
- Short signal path – Only 14 components between you and your music.
- Perfect partners – pair your Edge W with the Edge NQ to create your perfect system.
100W RMS into 8 Ohms; 200W RMS into 4 Ohms
<0.002% 1kHz at rated power (8 Ohms); <0.02% 20Hz – 20kHz at rated power (8 Ohms)
<3Hz – >80kHz +/-1dB
>93 dB
< -100dB
>113 dB
Input A1-A2 (unbalanced) 1.09V RMS
Input A3 (balanced) 47k Ohm; Input A1-A2 (unbalanced) 47k Ohm
Balanced, Unbalanced
Speakers, Loop out
1000W
<0.5W
150 x 460 x 405mm (5.9 x 18.1 x 15.9")
23.6kg (51.9lbs)
Edge W Power Amplifier; 1.5M Power Lead; Edge Link Cable; Edge W User Manual, Warranty Card
The Best Power-Amplifier we Have Ever Made
Edge W is made to be played loud. When you do turn it up, expect nothing but a dynamic and punchy sound that captures all the musicality of your songs. With just 14 hand-picked components, Edge W has one of the cleanest signal paths available. It delivers our breath-taking, unadulterated British sound – nothing added, nothing taken away.
Powerfully Subtle
For all its power, Edge W is remarkably detailed. The sound is finely balanced, with a musical depth and clarity that comes through with every note. It’s all down to how we chose the componentry inside – nothing was picked on price, specs or measured performance. We listened carefully and created our system with components that simply sounded the best. The end result is a power amplifier that truly brings an original recording to life like no other.
Just 14 Components in the Signal Path
Although minimal in its exterior design, Edge W has some complex audio engineering inside. To remove the barriers between you and your music, we have worked hard to minimise the number of components in the signal path. As a result, Edge W delivers a more faithful reproduction of the original recording; an impressively detailed three-dimensional
More Musical Detail
We pioneered the use of toroidal transformers in amplifiers, which led to improved performance. In Edge we take this one step further, using opposing symmetrytwin toroidal transformers. This cancels out electromagnetic interference whilst offering outstanding power and maintaining consistent tonality, no matter how loud it’s played.
Effortless Power Without Distortion
Using standard Class A amplifier technology wasn’t going to be efficient enough for Edge W. Instead we added a bias voltage to a traditional Class AB design, reducing distortion to inaudible levels. This unique configuration also produces less heat and makes the whole system much more effective.
Perfect Partners
Edgesystems are designed to work in perfect synchronisation. Match the Edge W with our most versatile Preamplifier Network player,Edge NQ, to create a hi-fi system with a sound, and a look, unlike anything else.
