KEF Ci130ER
The KEF Ci130ER is a discreet in-ceiling speaker from KEF’s Ci-E series, designed for high-quality sound with minimal visual impact. It uses KEF’s proprietary Uni-Q driver array to deliver wide, even sound coverage, and features weather-resistant construction and an ultra-thin bezel for seamless integration into homes, kitchens, bathrooms or commercial spaces.
KEF Ci130ER - Architectural Speaker
- Magnetic grille for easy fit and clean look.
- Compact form factor ideal for small to medium rooms.
- Recommended amplifier power: ~10–80 W.
- Frequency response approx. 52 Hz–20 kHz (±6 dB).
- 8 Ω impedance with ~87–90 dB sensitivity.
- Open-back design for natural sound in ceiling installs.
- Optional accessories: rough-in frame (RIF130R), rear enclosure (RNC130R) for better bass.
- Easy installation with universal cut-out and shallow mounting depth
8 Ohms
10-80W
1.2kg (2.7lbs)
90dB (2.83V/ 1m)
Diameter : 193.4mm (7.61in.)
Depth : 81mm (3.19n.)
Piece
52Hz - 20kHz (+/-6dB) open-backed
Diameter : 158mm (6.22in.)
2.5kHz
Ceiling Thickness (Maximum): 33mm (1.3 in.)
Ceiling Thickness (Minimum): 6mm (0.24 in.)
77.5mm (3.05in.)
LF: 130mm (5.25in.)
HF: 16mm (0.6in.)
RIF130R
RNC130R
Ci130ER
Heard but not seen, with unprecedented value and performance, KEF's Ci-E series of architectural speakers are designed and manufactured to the same exacting standards as all KEF's architectural offerings and features KEF's famed Uni-Q driver technology.
KEF's Uni-Q driver enables the mid-range and tweeter to act as a single point source. This patented technology allows the listener to sit anywhere in the room and still enjoy KEF's world-renowned sound and clarity without having to be positioned in the narrow "sweet-spot" found with conventional speaker designs.
The Ci-E Series also features KEF's Ultra-Thin Bezel (UTB) technology which offers the thinnest possible visible rim around the speaker assembly. The bezel and grill can be painted to match the interior décor.
The speakers in the Ci-E Series, are manufactured to Weather Resistant Construction standards: The grilles are coated via a proprietary process, the speakers include moisture-resistant terminations and finish materials, and the plastics are UV protected, allowing you to safely use these speakers in applications such as bathroom and kitchen.
